SPX Power Team Cyl 100 Ton 6-5/8" Stroke

$3,398.62
Pre Order Today
Item Number
C1006C

Aluminum bronze bearing reduces wear caused by off-center loads. Maximum sized springs speed piston return and increase spring life. Wide range of accessories available to thread onto piston rod, collar, or onto cylinder base. Single-Acting, Spring-Return. Rugged and high quality general purpose cylinder used for lifting and pressing.

Specifications

  • Cylinder Cap tons: 100
  • Stroke (in): 6-5/8
  • Oil cap (cu. in): 137
  • Bore Diameter (in): 5-1/8
  • Cylinder Effective Area (sq. in): 20.62
  • Internal Press at cap (psi): 9,695
  • Tons at 10,000 (psi): 103.1
  • Weight (lbs): 91
  • Retracted Height (in): 13-1/4
  • Extended Height (in): 19-7/8
  • Outside Diameter (in): 6-1/4
  • Collar Thread (in): 6-1/4-12
  • Piston Collar Thread Length (in): 2-1/4
  • Base to Port (in): 1-5/8
  • Piston Rod Diameter (in): 4-1/8
  • Rod Protrusion (in): 1/8
More Information
Item Number C1006C
Weight 115.000000
