SPX 17.5 TON CYLINDER 2" STROKE
Pre Order Today
Item Number
RT172
A proven design; used throughout industry for over 45 years. Cylinders withstand full “dead-end” loads. Compact design; ideal for applications in which space is limited. Basic head can be changed from a tapped hole to plain hole by simply changing insert. Pistons have “Power Tech” treatment for corrosion and abrasion resistance.
Specifications
- Cyl. Capacity (tons) Push: 17-1/2
- Stroke (in.): 2
- Oil Cap. (cu. in.) Push: 7.06
- Mounting Hole (in.): 11/32
- Cyl. Eff. Area (sq. in.): 3.53
- Int. Press at Cap. (psi): 9,915
- Tons at 10,000 (psi): 17.7
- Weight (lbs.): 14.6
- A: Retracted Height (in.): 6-7/8
- B: Extended Height (in.): 8-7/8
- C1: Outside Dia. (in.): 3-3/4
- C2: Outside Dia. (in.): 5-3/4
- L: Load Cap Dia. (in.): 1-3/4
- M: Load Cap Dia. (in.): 1 - 8
- N: Center Hole Dia. (in.): 1-1/32
- Z: Mounting Hole Location (in.): 1-1/2
| Item Number | RT172 |
|---|---|
| Weight | 30.000000 |
