SPX 20 TON, 6-1/4" STROKE BOTTLE JACK

Features

• Ideal for use in any number of industrial lifting and pushing applications
• All jacks can be used in the vertical, angled or horizontal positions
• Serrated or contoured saddles help stabilize the load for a safer lift
• All jacks meet ASME B30.1 standards and carry the Power Team Marathon Lifetime Warranty

Specifications

• Type/design: Bottle Jack
• Strokes to extend piston at max load capacity: 22 in
• Load capacity: 20 Ton
• Handle effort at rated capacity: 70 lb
• Stroke length: 6-1/4 in
• Pump handle length: 31-1/2 in
• Retracted height: 10-5/8 in
• Saddle diameter: 2 in
• Length of screw: 3-5/8 in
• Base dimensions: 7-3/16 x 5-1/16 in
• Extended height: 20-1/2 in
• Weight: 28.5 lb
