SPX POWER TEAM 20 TON HYDRAULIC 1-3/4" STROKE SINGLE ACTING CYLINDER
In stock
Only 1 left
Item Number
RSS202
Power Tech plated piston rods and gland nuts resist scoring and corrosion. Heavy duty return spring (except for double-acting models) provides fast piston return & low collapsed height. Coupler on 10 thru 50-ton models is angled upward 5° for added clearance. Grooved piston top keeps load from sliding. Cylinders can be “dead-ended” at full capacity. Removable carrying handles on 100 ton and 250-ton models.
Specifications
- Cyl Cap. (tons): 20
- Stroke (in.): 1-3/4
- Oil Cap. (cu. in.) Push: 7.7
- Bore Dia. (in.): 2-3/8
- Cylinder Effective Area (sq. in.) Push: 4.43
- Internal Press at Cap. (psi) Push: 9,029
- Tons at 10000 (psi) Push: 22.1
- Weight (lbs.): 9.9
- A: Retracted Height (in.): 3-3/4
- B: Extended Height (in.): 5-1/2
- C: Outside Dia. (in.): 3-9/16
- F: Base to Port (in.): 5/8
- H: Piston Rod Dia. (in.): 2-5/32
| Item Number | RSS202 |
|---|---|
| Weight | 11.000000 |
| Vendor Part Number | RSS202 |
