SPX 20 TON CYLINDER 7/16" STROKE

Features

• Low profile cylinder ideal for confined areas with heavy-duty return spring for faster retraction
• Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance
• Standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) minimize effects of off-center loading
• Unique heavy-duty spring provides fast piston return
• A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled)
• Oil ports are 3/8" NPTF
• Couplers on all cylinders, except RLS50, are angled upward for extra clearance

Specifications

• Stroke Length (in): 0.438
• Piston Rod Diameter (in): 1.125
• Series / Type: RLS-Series / Low Profile
• Actuation / Return: Single-Acting / Spring Return
• Cylinder Capacity (in): 20
• Oil Capacity (in³): 2.00
• Retracted Height (in): 2.00
• Extended Height (in): 2.438
• Effective Area (in²): 4.430
• Tons at 10000 psi: 22.15
• Max Pressure: 10,000
• Bore Size (in):2.375
• Base to Port (in): 0.656
• Dimensions (in): 3.00 x 4.00
• Cylinder Material: Steel
• Weight (lbs): 5.60
