SPX 30 TON CYLINDER 1/2" STROKE
In stock
Only 1 left
Item Number
RLS300
Cylinder body, piston and gland nut “Power Tech” treated for corrosion and abrasion resistance. Standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) minimize effects of off-center loading. Unique heavy duty spring provides fast piston return. A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled). Oil ports are 3/8" NPTF. Couplers on all cylinders, except RLS50, are angled upward for extra clearance.
Specifications
- Stroke Length (in): 0.500
- Piston Rod Diameter (in): 1.375
- Series / Type: RLS-Series / Low Profile
- Actuation / Return: Single-Acting / Spring Return
- Cylinder Capacity (in): 30
- Oil Capacity (in³): 3.200
- Retracted Height (in): 2.313
- Extended Height (in): 2.813
- Effective Area (in²): 6.492
- Tons at 10000 psi: 32.46
- Max Pressure: 10,000
- Bore Size (in):2.875
- Base to Port (in): 0.719
- Dimensions (in): 3.750 x 4.50
- Cylinder Material: Steel
- Weight (lbs): 8.60
Features
- Low profile cylinder ideal for confined areas with heavy-duty return spring for faster retraction
- Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance
- Standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) minimize effects of off-center loading
- Unique heavy-duty spring provides fast piston return
- A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled)
- Oil ports are 3/8" NPTF
- Couplers on all cylinders, except RLS50, are angled upward for extra clearance
| Item Number | RLS300 |
|---|---|
| Weight | 10.000000 |
| Vendor Part Number | RLS300 |
