SPX 30 TON CYLINDER 2-1/2" STROKE
Pre Order Today
Item Number
RT302
A proven design; used throughout industry for over 45 years. Cylinders withstand full “dead-end” loads. Compact design; ideal for applications in which space is limited. Basic head can be changed from a tapped hole to plain hole by simply changing insert. Pistons have “Power Tech” treatment for corrosion and abrasion resistance.
Specifications
- Cyl. Capacity (tons) Push: 30
- Stroke (in.): 2-1/2
- Oil Cap. (cu. in.) Push: 15.7
- Mounting Hole (in.): 15/32
- Cyl. Eff. Area (sq. in.): 6.28
- Int. Press at Cap. (psi): 9,554
- Tons at 10,000 (psi): 31.4
- Weight (lbs.): 28.2
- A: Retracted Height (in.): 8-7/16
- B: Extended Height (in.): 10-15/16
- C1: Outside Dia. (in.): 4-1/4
- C2: Outside Dia. (in.): 7-1/2
- L: Load Cap Dia. (in.): 2-1/4
- M: Load Cap Dia. (in.): 1-1/4 - 7
- N: Center Hole Dia. (in.): 1-19/64
- Z: Mounting Hole Location (in.): 1-13/16
| Item Number | RT302 |
|---|---|
| Weight | 30.000000 |
| Vendor Part Number | RT302 |
