SPX 5 TON, 3/4" STROKE SIDEWINDER JACK

Features

• The Compact Sidewinder Mini Jacks offer retracted heights of just 2-1/2 in for the smallest jack and 55-1/4 in for the 20 ton; this allows you to slip these jacks into the narrowest of crevices
• Jacks operate either horizontally or vertically
• Handles function in line with base for easier use in confined spaces
• The perfect addition to any toolbox, this remarkable little jack has multiple uses that are limited only by your imagination
• Use it as a jack or a spreader; use it to turn your mechanical gear puller (puller capacity must match jack capacity) into a hydraulic puller

Specifications

• Type/design: Sidewinder Mini Bottle Jack
• Strokes to extend piston at max load capacity: 30 in
• Load capacity: 5 Ton
• Handle effort at rated capacity: 57 lb
• Stroke length: 3/4 in
• Pump handle length: 9-7/16 in
• Retracted height: 2-1/2 in
• Saddle diameter: 1-9/64 in
• Length of screw: 2-1/2 in
• Base dimensions: 2-29/32 in Diameter
• Extended height: 3-3/8 in
• Weight: 4.2 lb
