SPX 50 TON CYLINDER 2-3/8" STROKE
In stock
Only 1 left
Item Number
RSS502
Power Tech plated piston rods and gland nuts resist scoring and corrosion. Heavy duty return spring (except for double-acting models) provides fast piston return & low collapsed height. Coupler on 10 thru 50-ton models is angled upward 5° for added clearance. Grooved piston top keeps load from sliding. Cylinders can be “dead-ended” at full capacity. Removable carrying handles on 100 ton and 250-ton models.
Specifications
- Cyl Cap. (tons): 50
- Stroke (in.): 2-3/8
- Oil Cap. (cu. in.) Push: 22.8
- Bore Dia. (in.): 3-1/2
- Cylinder Effective Area (sq. in.) Push: 9.62
- Internal Press at Cap. (psi) Push: 10,393
- Tons at 10000 (psi) Push: 48.1
- Weight (lbs.): 23.2
- A: Retracted Height (in.): 5
- B: Extended Height (in.): 7-3/8
- C: Outside Dia. (in.): 4-7/8
- F: Base to Port (in.): 3/4
- H: Piston Rod Dia. (in.): 3-1/8
| Item Number | RSS502 |
|---|---|
| Weight | 25.000000 |
| Vendor Part Number | RSS502 |
