SPX 50 TON CYLINDER 3" STROKE
Pre Order Today
Item Number
RT503
A proven design; used throughout industry for over 45 years. Cylinders withstand full “dead-end” loads. Compact design; ideal for applications in which space is limited. Basic head can be changed from a tapped hole to plain hole by simply changing insert. Pistons have “Power Tech” treatment for corrosion and abrasion resistance.
Specifications
- Cyl. Capacity (tons) Push: 50
- Stroke (in.): 3
- Oil Cap. (cu. in.) Push: 29.4
- Mounting Hole (in.): 21/32
- Cyl. Eff. Area (sq. in.): 9.81
- Int. Press at Cap. (psi): 10,193
- Tons at 10,000 (psi): 49.1
- Weight (lbs.): 56
- A: Retracted Height (in.): 10-9/16
- B: Extended Height (in.): 13-9/16
- C1: Outside Dia. (in.): 5-7/8
- C2: Outside Dia. (in.): 9-3/8
- L: Load Cap Dia. (in.): 2-7/8
- M: Load Cap Dia. (in.): 1-5/8 – 5-1/2
- N: Center Hole Dia. (in.): 1-43/64
- Z: Mounting Hole Location (in.): 2-3/8
| Item Number | RT503 |
|---|---|
| Weight | 60.000000 |
