SPX Power Team Cyl 50 Ton 5/8" Stroke
$1,355.99
In stock
Only 1 left
Item Number
RLS500S
Cylinder body, piston and gland nut “Power Tech” treated for corrosion and abrasion resistance. Standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) minimize effects of off-center loading. Unique heavy duty spring provides fast piston return. A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled). Oil ports are 3/8" NPTF. Couplers on all cylinders, except RLS50, are angled upward for extra clearance.
Features
- Low profile cylinder ideal for confined areas with heavy-duty return spring for faster retraction
- Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance
- Standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) minimize effects of off-center loading
- Unique heavy-duty spring provides fast piston return
- A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled)
- Oil ports are 3/8" NPTF
- Couplers on all cylinders, except RLS50, are angled upward for extra clearance
Specifications
- Stroke Length (in): 0.625
- Piston Rod Diameter (in): 1.750
- Series / Type: RLS-Series / Low Profile
- Actuation / Return: Single-Acting / Spring Return
- Cylinder Capacity (in): 50
- Oil Capacity (in³): 6.00
- Retracted Height (in): 2.625
- Extended Height (in): 3.250
- Effective Area (in²): 9.621
- Tons at 10000 psi: 48.10
- Max Pressure: 10,000
- Bore Size (in): 3.50
- Base to Port (in): 0.844
- Dimensions (in): 4.50 x 5.50
- Cylinder Material: Steel
- Weight (lbs): 14.00
Item Number | RLS500S |
---|---|
Weight | 20.000000 |
