SPX 5 TON CYLINDER 9/16" STROKE

Features

• Low profile cylinder ideal for confined areas with heavy-duty return spring for faster retraction
• Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance
• Standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) minimize effects of off-center loading
• Unique heavy-duty spring provides fast piston return
• A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled)
• Oil ports are 3/8" NPTF
• Couplers on all cylinders, except RLS50, are angled upward for extra clearance

Specifications

• Stroke Length (in): 0.563
• Piston Rod Diameter (in): 0.625
• Series / Type: RLS-Series / Low Profile
• Actuation / Return: Single-Acting / Spring Return
• Cylinder Capacity (in): 5
• Oil Capacity (in): 0.620
• Retracted Height (in): 1.625
• Extended Height (in): 2.188
• Effective Area (in): 0.994
• Tons at 10000 psi: 4.97
• Max Pressure: 10,000
• Bore Size (in): 1.125
• Base to Port (in): 0.750
• Dimensions (in): 1.625 x 2.563
• Cylinder Material: Steel
• Weight (lbs): 2.20
