SPX 60 TON CYLINDER 6" STROKE

Features

• Center hole cylinder ideal for pulling and tensioning cables, anchor bolts with interchangeable piston head inserts
• Interchangeable piston head inserts (provide versatility of application)
• 12, 20, 30, 50, 60 Ton Single-Acting Models Feature Threaded Collar; Model RH203 and RHA306 do not feature the collar thread
• Withstands full "dead-end" loads
• Corrosion resistant standpipe has "Power Tech" treatment
• All cylinders except RH120 are furnished with a 9796 3/8" NPT female half coupler
• Aluminum cylinder body and piston are featured on the RHA306 cylinder

Specifications

• Stroke length: 6 in
• Bore size: 3.960 in
• Piston rod diameter: 3.594 in
• Base to port: 1.00 in
• Series / type: RH-Series / Center Hole
• Outside diameter: 6.250 in
• Actuation / return: Single-Acting / Spring Return
• Center hole diameter: 2.125 in
• Cylinder capacity: 60 tons
• Mounting holes and bolt circle: ½-13 x 5-1/8
• Oil capacity: 73.860 in
• Collar thread: 6-1/4
• Retracted height: 12.250 in
• Collar thread length: 2.500 in
• Extended height: 18.250 in
• Insert thread size: 3-12
• Effective area: 12.310 in
• Cylinder material: Aluminum
• Tons at 10000 psi: 61.60 tons
• Weight: 78.00 lb
• Max pressure: 10000 psi
