JET JWBS-18-3, 18" BANDSAW 3HP, 230V
Pre Order Today
Item Number
714750
The heavy-duty cast-iron fence system is built to give you the sturdiness and support you need for every project and features a micro-adjust dial for exact placement. The table is slotted and the guide post has a stress-free magnetic door on the front for efficient blade changes. Large, independently adjustable guides are tool-less to save you time on set up.
Features
- 16" Resaw capacity for cutting large pieces of wood, slicing veneers and cutting book matched panels
- 27-1/4" x 20" precision ground cast iron table for added stability and work support.
- 4" dust collection port.
- Blade tracking window provides clear view of blade during tracking.
- Cast iron handwheels and ergonomically designed knobs make adjustments smooth and easy.
- Cast iron trunnion for maximum support and stability.
- Conveniently located dual 4" dust collection ports catch dust and chips at the source.
- Easy-to-read blade tension scale can be viewed through upper door window.
- Fence system features a micro-adjustable, dual-position side plate.
- Heavy duty tensioning with quick release features three settings: full tension, partial tension and full release.
- Rigid, four-sided guide post with rack and pinion adjustment for optimum blade support.
- Round table insert features leveling screws for precise adjustment.
- Single knob adjustment simplifies the blade tracking process.
- Slotted table allows for front blade removal.
- Table tilts 5° left and 45° right to accommodate a wide variety of cuts.
Specifications
- Band Saw Size/Wheel Diameter: 18-1/2"
- Cutting Capacity Width: 18"
- Cutting Capacity Height: 16"
- Minimum Saw Blade Width: 1/8"
- Motor Power (HP) 3
- Table Height from Floor: 37"
- Dust Collection Minimum CFM Required (CFM) 400
- Prewired Voltage (V.) 115
- Motor Amps 15/7.5
- Recommended Circuit Size (Amps.) 20
| Item Number | 714750 |
|---|---|
| Weight | 200.000000 |
