MAGSWITCH MLAY1000 LIFTING MAGNET (330LB)
Pre Order Today
Item Number
8100088
Built for heavy-duty lifting, our magnet technology is powerful without the need for a power source. Safely lock in the on and off position with a 3:1 Safe Working Load of 333 pounds. The pivoting lift hook offers the stability to lift from horizontal to vertical.
Features
- Magnetic field turns completely on and off mechanically.
- Does not use an electrical power source.
- Magnet stays clean.
- Holds flat and round surfaces of steel.
- Safety locking handle.
- Full swivel hook allows for lifting from the top or side.
- Strong grip on thin material and uneven surfaces.
Specifications
- Max Breakaway: 1000 lbs / 453.5 kg
- 3:1 Safe Working Load: 333 lbs / 151 kg
- 2:1 Shear Working Load: 50 lbs / 22.6 kg
- Full Saturation Thickness: 0.75 in / 19 mm
- Minimum Thickness for De-Stack: 0.75 in / 19 mm
- Net Weight: 11.5 lbs / 5.2 kg
- Dimensions: 5.8 x 2.8 x 10 in / 147.3 x 71.1 x 254 mm
- Magnetic Pole Footprint: 108 mm x 72 mm
| Item Number | 8100088 |
|---|---|
| Weight | 30.000000 |
| Vendor Part Number | 8100088 |
