SPX 55 TON 2" STROKE CYLINDER
Pre Order Today
Item Number
C552C
Aluminum bronze bearing reduces wear caused by off-center loads. Maximum sized springs speed piston return and increase spring life. Wide range of accessories available to thread onto piston rod, collar, or onto cylinder base. Single-Acting, Spring-Return. Rugged and high quality general purpose cylinder used for lifting and pressing.
Specifications
- Cylinder Cap tons: 55
- Stroke (in): 2
- Oil cap (cu. in): 22.1
- Bore Diameter (in): 3-3/4
- Cylinder Effective Area (sq. in): 11.04
- Internal Press at cap (psi): 9,959
- Tons at 10,000 (psi): 55.2
- Weight (lbs): 32.5
- Retracted Height (in): 6-7/8
- Extended Height (in): 8-7/8
- Outside Diameter (in): 5
- Collar Thread (in): 5-12
- Piston Collar Thread Length (in): 2-3/16
- Base to Port (in): 1-3/8
- Piston Rod Diameter (in): 3-1/8
- Piston Int. Thread and Depth (in): None
- Rod Protrusion (in): 1/8
| Item Number | C552C |
|---|---|
| Weight | 35.000000 |
