PROTO 1" DRIVE IMPACT SOCKET 15/16" 8 POINT

Features

• Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
• Tight tolerances for snug fit on fastener.
• Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
• Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
• Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
• Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
• Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.

Specifications

• SIZE [IN] 15/16
• NUT END OUTSIDE DIAMETER [IN] 2
• DRIVE END OUTSIDE DIAMETER [IN] 2
• NUT DEPTH [IN] 5/8
• BOLT CLEARANCE DEPTH [IN] 1-3/8
• OVERALL LENGTH [IN] 2-5/8
• WEIGHT [LBS] 1.52
• DRIVE SIZE [IN] 1
• POINT SIZE 8
• FINISH Black Oxide
• LENGTH TYPE Standard
