SPX ENFORCER 100 UNIVERSAL PULLER

Features

• Adjustable jaws mean they always pull on a flat surface. Retaining chain holds jaws in place during positioning.
• Grip-O-Matic® feature means jaws grip progressively tighter as more pulling force is applied.
• 100 ton hydraulic cylinder is single-acting, spring return type with a maximum working pressure of 10,000 psi.
• Lifting bracket allows puller to be lifted if the workpiece center is more than 36" off the floor.
• Adjusting screw allows operator to move vertical position of the puller.
• Spring loaded feature means Enforcer 100 will align itself on uneven pulls.
• Hydraulic pump is a 2-stage, high pressure unit controlled by remote hand switch with 25 foot cord.
• Tow bar provides puller with plenty of mobility.
• Pushing adapters have a diameter of 4 1/8" and 2 1/2".

Specifications

• Vertical Stroke Adjust (in): 12-36
• Overall Length (in): 94
• Max Thickness word piece: 12
• Wheel Diameter (in): 8
• Min Spread (in): 15
• Reach min Spread (in): 42
• Max Spread (in): 48
• Reach max Spread (34): 34
• Puller Jaw Tip (in): 1, 2-1/4, 5
• Cylinder Height (in): 10-1/4
• Weight (lbs): 890
